tire building machines
tire building machine-yb亚博全站首页
| 规格 项目 | lc-0 | lc-1b | lcb-2b | lcx-3b | lcx-4b | ||
| 成型轮胎规格 specification of building type | inch | 4.00-12～ 6.5-15 | 6.00-13～ 7.5-16 | 7.50-20～10.00-20 | 11.00-20～ 14.00-24 | 25～28 | |
| 与成型机头配合轴径 shaft dia.matched with building | ㎜ | 40 | 50 | 70 | 75 | 100 | |
| 窗布筒最大宽度 max. width of band | ㎜ | 670 | 730 | 980 | 1260 | 2100 | |
| 下压轴允许辊压最大宽度 permitted max.rolling width of the lower press roller | ㎜ | 420 | 580 | 570 | 780 | 1200 | |
| 后压轴向分离宽度范围 axial separation width ranges of the rear press roller | ㎜ | 0～700 | 230～580 | 290～670 | 330～910 | 860～1980 | |
| 主电机功率 main motor power | kw | 3/5 | 3/5 | 3/5 | 6.5/11 | 9/15 | |
| 外形尺寸 overall dimensions | l | ㎜ | 2750 | 4166 | 4470 | 4900 | 6560 |
| w | ㎜ | 1595 | 1480 | 1780 | 1820 | 3604 | |
| h | ㎜ | 1440 | 1542 | 1658 | 1950 | 2665 | |
| 约重about weight | t | ～2.7 | ～3 | ～4.5 | ～5.5 | ～11 | |
